Conductor: 23 AWG Solid Bare Copper
Number of Conductors or Pairs: 4 Pair
Jacket Material: Polyvinyl Chloride
Nominal Overall Cable Diameter: 0.240 in.
Approximate Cable Weight: 34 lbs/1000 ft.
Electrical & Physical Properties
Temperature Rating: 0 degrees celsius to 50 degrees celsius (Installation); -2 degrees celsius to 60 degrees celsius (Operation)
Velocity of Propagation: 70%
Mutual Capacitance: 14 pF/ft Nominal
Capacitance Unbalance: 330 pF/ft maximum
Maximum Conductor D.C.R.: 28.6 ohm/1000 ft
Maximum D.C.R. Unbalance: 3%
Maximum Delay Skew: 18 ns/100m
Minimum Bend Radius: 1.0 in.
