CAT6 24 AWG UTP 8C Stranded Bare Copper 550MHz PVC Jacket Black 1000'

Sorry, this product has been discontinued.

Category-6, 24AWG, UTP, 8C Stranded Bare Copper, 550MHz, PVC Jacket 1000ft. BLACK

FEATURES AND BENEFITS: • High-Performance Data Cable • 550MHz Bandwith for Data Applications, Fast Ethernet and 155Mbps TP-PMD/CDDI • Category-6 Unshielded Twisted Pair • Easily Identified Color-Striped Pairs • Exceeds EIA/TIA 568-B.2-1, ISO/IEC-11801 • 1000ft Pull Box

Technical Data Rated Temperature (ºC) 70 Rated Voltage (V) 30 Product Standard Certification CM Flammability Test IEC-332-1
Conductor Stranded Bare Copper Size 24 AWG
Insulation PE Average Thickness (mm) 0.20 Min. Point Thickness (mm) 0.18 Insulation Diameter (±0.005mm) 0.98 Twisted Pair Diameter (±0.01) 1.96
Seperator PP
Assembly Diameter 4.80
Jacket PVC Average Thickness (mm) 0.60 Min. Point Thickness (mm) 0.54 Outer Diameter (±0.10mm) 6.20 Rip Cord Yes Color Black
Color of Pairs Pair 1 Blue,White-Blue Pair 2 Orange,White-Orange Pair 3 Green,White-Green Pair 4 Brown,White-Brown
