CAT6 24 AWG UTP 8C Stranded Bare Copper 550MHz PVC Jacket Gray 1000'

CAT6 24 AWG UTP 8C Stranded Bare Copper 550MHz PVC Jacket Gray 1000' Vertical Cable

Sorry, this product has been discontinued.

Description

Category-6, 24AWG, UTP, 8C Stranded Bare Copper, 550MHz, PVC Jacket 1000ft. GRAY

FEATURES AND BENEFITS:
• High-Performance Data Cable
• 550MHz Bandwith for Data Applications, Fast Ethernet and 155Mbps TP-PMD/CDDI
• Category-6 Unshielded Twisted Pair
• Easily Identified Color-Striped Pairs
• Exceeds EIA/TIA 568-B.2-1, ISO/IEC-11801
• 1000ft Pull Box
Technical Data
Rated Temperature (ºC) 70
Rated Voltage (V) 30
Product Standard Certification CM
Flammability Test IEC-332-1

Conductor Stranded Bare Copper
Size 24 AWG

Insulation PE
Average Thickness (mm) 0.20
Min. Point Thickness (mm) 0.18
Insulation Diameter (±0.005mm) 0.98
Twisted Pair Diameter (±0.01) 1.96

Seperator PP

Assembly Diameter 4.80

Jacket PVC
Average Thickness (mm) 0.60
Min. Point Thickness (mm) 0.54
Outer Diameter (±0.10mm) 6.20
Rip Cord Yes
Color GRAY

Color of Pairs
Pair 1 Blue,White-Blue
Pair 2 Orange,White-Orange
Pair 3 Green,White-Green
Pair 4 Brown,White-Brown
