RG59 Siamese, 500', reel in box, White, (1) 20AWG Solid copper clad steel conductor with 95% Copper Clad Aluminum Braid and (2) unshielded 18AWG Stranded Twisted Pair Power Cables, Siamese PVC Jacket for CCTV
FEATURES AND BENEFITS:
• RG59 Type Coaxial Cable with One Pair of 18AWG Power Cable
• 20AWG Solid Copper Clad Steel Conductor
• Unshielded 18 AWG Stranded Twisted Pair Power Cables
• Indoor Cable Application for: CCTV
• RoHS Compliant, ISO9001:2000
• Available in a 500ft Reel Box
Physical Characteristics:
Inter Conductor Coax
Size 20 AWG
Material Copper Clad Steel (Solid)
Construction 0.81±0.1mm
Dielectric
Material Foamed PE
Diameter 3.66±0.10mm
Color White
Braid 95%x16x8x0.12±0.005mm CCA
Jacket
Material PVC
Diameter 6.1±0.10mm
Color White
Power Cable 2 Conductor BC
Size 18AWG PVC
Electrical Characteristics
Sparker Test 3000VAC
Impedance 75±3 Ohms
Capacitance 53±3pF/m
Velocity of Propagation 85%
Return Loss (5~470Mz)≥22dB
(470~1000Mz)≥20dB
Mechanical Characteristics
Operating Temp. -30ºC to 75ºC
