Features:
- High quality imaging with 8 MP resolution
- 24/7 colorful imaging
- Clear imaging against strong backlight due to 130 dB WDR technology
- Efficient H.265+ compression technology
- Focus on human and vehicle targets classification based on deep learning
- Built-in microphone for real-time audio security
- Water and dust resistant (IP67)
- MD2.0
Specification:
Camera
- Image Sensor: 1/1.8" Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
- Min. Illumination: Color: 0.0008 Lux @ (F1.0, AGC ON),0 Lux with white light
- Shutter Time: 1/3 s to 1/100,000 s
- Day ＆ Night: 24/7 color imaging
- Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
- Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length ＆ FOV: 2.8 mm, horizontal FOV 104°, vertical FOV 55°, diagonal FOV 127° & 4 mm, horizontal FOV 93°, vertical FOV 46°, diagonal FOV 112°
- Lens Mount: M16
- Iris: Type Fixed
- Aperture: F1.0
- Depth of Field: 2.8 mm: 3.4 m to ∞ & 4 mm: 3.8 m to ∞
DORI
- DORI: 2.8 mm: D: 91 m, O: 36 m, R: 18 m, I: 9 m & 4 mm: D: 111 m, O: 44 m, R: 22 m, I: 11 m
Illuminator
- Supplement Light Type: White Light
- Supplement Light Range: Up to 98ft(30 m)
- Smart Supplement Light: Yes
Video
Main Stream
50 Hz:
20 fps (3840 × 2160)
25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
20 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Video Compression
- Main stream: H.265+/H.265/H.264+/H.264
- Sub-stream: H.265/H.264/MJPEG
- Third stream: H.265/H.264
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline Profile/Main Profile/High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR/VBR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region of Interest (ROI): 1 fixed region for main stream and sub-stream
Audio
- Audio Type: Mono sound
- Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Audio Bit Rate: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to
- 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Environment Noise Filtering: Yes
Network
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP,
- IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface ( Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
- User/Host: Up to 32 users
- 3 user levels: administrator, operator, and user
- Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest
authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network
Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS
1.2, TLS 1.3, host authentication (MAC address)
Web Browser
- Plug-in required live view: IE10+
- Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 12+
- Local service: Chrome 57.0+, Firefox 52.0+
- Image Parameters Switch: Yes
- Image Setting: Mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
- adjustable by client software or web browser
- Day/Night Switch: Day, Night, Auto, Schedule
- Wide Dynamic Range (WDR): 130 dB
- SNR: ≥ 52 dB
- Image Enhancement: BLC, HLC, 3D DNR
- Privacy Mask: 4 regions of privacy mask
Interface
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256
- GB
- Built-in Microphone: Yes
- Reset Key: Yes
Event
- Basic Event: Motion detection (support alarm triggering by specified target types (human and
- vehicle)), video tampering alarm, exception
- Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting
- detection (support alarm triggered by specified target types (human and vehicle)),
- scene change detection
- Linkage: Upload to NAS/memory card/FTP, notify surveillance center, send email, trigger
- recording, trigger capture
General
- Power: 12 VDC ± 25%, 0.79 A, max. 9.5 W, Ø 5.5 mm coaxial power plug, reverse polarity
- protection
- PoE: 802.3af, Class3, 36 V to 57 V, 0.29 A to 0.18 A, max. 10.5
- Material: Metal except for trim ring
- Dimension: Ø 138.3 mm × 115.4 mm (Ø 5.4" × 4.5")
- Package Dimension: 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9")
- Weight: Approx. 770 g (1.7 lb.)
- With Package Weight: Approx. 1040 g (2.3 lb.)
- Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- General Function: Anti-flicker, heartbeat, mirror, flash log, password reset via email, pixel counter, password protection, one-key reset, three streams
Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak,
French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian,
Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai,
Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Approval
- EMC: CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN
- 50130-4: 2011 +A1: 2014,FCC: 47 CFR Part 15, Subpart B
- Protection: IP67: IEC 60529-2013
Safety
- UL: UL 62368-1,
- CB: IEC 62368-1: 2014+A11,
- CE-LVD: EN 62368-1: 2014/A11: 2017
Environment
- CE-RoHS: 2011/65/EU,
- WEEE: 2012/19/EU,
- Reach: Regulation (EC) No 1907/2006
