16-Channel NVR 12MP 8 PoE Ports AI Light Network Video Recorder (No HDD)

NR-K116H-P8 AI Light 16-Channel 12MP 8 PoE Ports Network Video Recorder 1HDD (No HDD included)

16CH 12MP NVR with 8CH POE ports,128Mbps, 16CH input max, 1 x SATA, 9x RJ-45, Audio I/O 1/1, Plug & Play With AI Management Function

• 16-channel IP camera NVR
• Supports up to 12MP recording
• HDMI output up to 4K resolution
• H.265/H.265+ video compression
• 8-port built-in PoE switch (72W total)
• Supports up to 10TB HDD
• ONVIF Profile S & T compatible
• Mobile viewing on iPhone and Android
• Two-way audio and remote playback supported

Specifications

System

• Processor: Dual-Core Cortex-A53
• Operating System: Embedded Linux

Video

• IP Camera Support: Up to 16 channels
• Supported Resolutions: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p, D1, CIF
• Video Outputs:
  • 1 × HDMI
  • 1 × VGA

Audio

• Audio Input: 1 × RCA (supports audio from up to 16 IP cameras)
• Audio Output: 1 × RCA Line Out + HDMI audio
• Compression: G.711A / G.711U
• Bit Rate: 64 kbps
• Two-Way Audio (Intercom): Supported

Alarm & Motion Detection

• Alarm Inputs/Outputs: Not available
• Motion Detection: 16 channels, up to 396 detection zones per channel
• Trigger Actions:
  • Recording
  • Email notifications
  • FTP upload
  • Snapshot capture
  • On-screen alerts

Display Features

• HDMI Resolution Support:
  • 4K (3840 × 2160)
  • 2K (2560 × 1440)
  • 1080p, 720p, and lower resolutions
• VGA Resolution Support:
  • Up to 1920 × 1080
• Multi-Screen Display Modes:
  • 1, 4, 6, 8, 9, 10, 13, or 16 camera views
• Digital Zoom: Yes
• On-Screen Display (OSD):
  • Camera name
  • Time/date
  • Recording status
  • Motion alerts
  • Event alarms

Recording

• Video Compression:
  • H.265
  • H.265+
  • H.264
  • H.264+
• Maximum Recording Resolution: 12MP
• Recording Modes:
  • Manual
  • Scheduled (Timer)
  • Motion Detection
  • Smart Events
• Recording Performance:
  • Up to 16 channels at 4K/5MP/4MP/3MP/1080p in real-time (25fps PAL or 30fps NTSC)

Playback & Backup

• Local Playback:
  • Up to 1 channel at 12MP
  • Up to 16 channels at 720p or D1
• Decoding Performance: 1080p @ 210 fps
• Remote Playback: Supported
• Search Options:
  • Time
  • Motion
  • Smart Events
  • Pictures
  • Tags
  • Logs
• Playback Controls:
  • Play
  • Pause
  • Fast Forward/Rewind
  • Frame-by-Frame
  • Digital Zoom
  • Clip Export
  • Audio Playback
• Backup Methods:
  • USB storage
  • Network backup

Network

• Network Port: 1 × Gigabit RJ45 (10/100/1000 Mbps)
• Incoming Bandwidth: 128 Mbps
• Outgoing Bandwidth: 80 Mbps
• Protocol Support:
  • IPv4 / IPv6
  • HTTP / HTTPS
  • DHCP
  • FTP
  • SMTP
  • DDNS
  • RTSP / RTCP
  • UPnP
  • PPPoE
  • P2P
• ONVIF Compatibility:
  • Profile S
  • Profile T
• Browser Support:
  • Edge
  • Internet Explorer 8–11
  • Chrome
  • Firefox
  • Safari
• CMS Software:
  • Windows 7 / 8 / 10 / 11
  • macOS
• Mobile App Support:
  • iPhone (iOS)
  • Android
• Cloud Access: Yes

PoE (Power over Ethernet)

• PoE Ports: 8 independent 100 Mbps ports
• Per-Port Power:
  • 30W (802.3at)
  • 15W (802.3af)
• Total PoE Power Budget: 72W
• Features:
  • Plug-and-play camera connection
  • Extended mode up to 200m network cable distance

Storage

• Drive Bays: 1 × SATA (3.5")
• Maximum HDD Capacity: 10TB
• eSATA: Not supported

General

• Languages: 20+ languages including English, Spanish, French, German, Italian, Portuguese, Russian, Arabic, Korean, Japanese, Dutch, Polish, Czech, Greek, Ukrainian, and more
• USB Ports: 2 × USB 2.0
• RS485: Not available
• Power Supply: DC 48V / 1.87A
• Power Consumption: ≤10W (without HDD)
• Operating Temperature: -10°C to 50°C (14°F to 122°F)
• Humidity: 10%–90%
• Dimensions: 260 × 230 × 43 mm (10.2 × 9.1 × 1.7 in)
• Weight:
  • Net: 0.78 kg (without HDD)
  • Gross: 1.52 kg (without HDD)
